Sydney, New South Wales May 15, 2022 (Issuewire.com) - Electrotechnik builds a range of electrical design software packages based on the latest IEC standards, powerful algorithms, and cloud technology.
ELEK Cable HV Software is for custom cable current rating calculations in accordance with IEC 60287.
With the new Version 5.0 release, there are added the FEM module which performs 2D finite element analysis for buried cable systems.
The finite element method (FEM) is the most accurate for HV cable current rating calculations and now it's available for the users.
The new FEM module allows users to model installation conditions that extend way beyond the limitations of the IEC Standards.
Completely custom installations can be modelled which includes:
- Multiple backfills - which are zones of soil with different thermal
- Filled troughs - concrete troughs of any size, buried at ground level or below ground and filled with soil with custom resistivity.
- Multiple circuits in any arrangement - any number of cables or cable types in any
- Direct buried cables or in
- Non-isothermal ground surface - very important for accurate current rating calculations especially for shallow cables or soils of low
- Automatic meshing where the FEM calculations are completely automated for the highest
Simply add objects to the model, specify their properties and move the objects of the model using the mouse (or key cursors) into any custom configurations.
For technical info about Cable HV Software visit: https://elek.com.au/electrical-software/elek-cable-high-voltage/
Electrotechnik believes the software needs to be feature-rich, and user interfaces should be both beautiful and simple, the simpler the better.
Impressive Metrics:
- 10,000+ Licenses Sold
- 40+ Countries Sold To
- 5,000+ Companies Sold To
Contact us to learn more about the Power System Analysis and Design Software.
For more information: https://elek.com.au/.
